ST-525 Inline Fluorescein Sensor

The Fluorescein Sensor for Industrial Boiler & Process Water Applications.

Utilizes LED light sources to determine the concentration of Fluorescein (0–60ppb). Use the MA-WB Bluetooth® Adapter to enable wireless monitoring, calibration & cleanliness diagnostics via the uPyxis® app!

CE Mark

$1,995.00

Description

The ST-525 offers a proprietary design that utilizes LED light sources for the direct measurement of Fluorescein. This simple, smart sensor is perfect for a water treatment professional working in industrial boiler water and process treatment applications. The ST-525 offers proprietary Pyxis Lab® algorithms to determine the concentrations of Fluorescein at levels as high as 60ppb. While simultaneously measuring light loss through the optical channel to determine sensor cleanliness.

The ST-525 offers a combination of 4-20mA as well as RS-485 Modbus output signals. It is Bluetooth Enabled for wireless cleanliness diagnostics and calibration when used with MA-WB or PowerPACK Series. Easily connect to the uPyxis APP for Mobile or Desktop devices. The ST-525 Series is provided in CPVC with the standard Pyxis ST-001 inline 3⁄4” FNPT Tee assembly, 5-foot bulk-head cable with quick adapter and 1.5ft flying lead cable with quick adapter, enabling rapid wiring to any microprocessor controller, PLC or DCS system.

Specifications

Item ST-525 Inline Fluorescein Sensor
Part Number 50665
Fluorescein Output Scale 0-60ppb
4-20mA Span via uPyxis® 20mA SPAN value may be adjusted to less than max range via uPyxis®
Fluorescein Resolution ±0.2ppb
Calibration Two Point Calibration against DI Water + Fluorescein Calibration Standard
Power Supply 22-26VDC, Power Consumption – 1W
Outputs Isolated 4-20mA Analog & Isolated RS-485 Digital – 7-Pin
Installation ST-001 Inline Tee (PROVIDED), 3/4inch FNPT
Weight 170g (0.37lbs)
Operation Pressure 100psi (6.9Bar)
Operation Temperature 4-49 °C (40-120 °F)
Storage Temperature -20-60 °C (40-120 °F)
Material UPVC
Rating IP67, Dustproof & Waterproof
Regulation CE + RoHS
Dimensions 6.8in (172.7mm) L x 1.44in (36.6mm) D
Cable Length 1.5m 7-Pin Bulkhead with Adapter + 1.5m 7-Pin Flying Lead with Adapter



Support Documents

ST-525 Series User Manual V1.04

ST-525 Data Sheet
